6 speed Metal Gearbox for CISON V8 Engine V4 ENGINE

Pay attention to the difference between V4 and V8 versions, choose according to your own CISON

brand:cison
Note: This is a CISON v8 gearbox. If your engine brand is not CISON, I cannot guarantee that it can be installed. You need to make some modifications yourself. I cannot provide instructions or any technical guidance. If you have no modification experience, please do not buy it. Once you buy it, it is assumed that you have agreed to this clause!
The power shift gearbox comes with a multi-plate clutch, and there is no need to switch the clutch when shifting gears.
It can run at idle speed, and the shifting speed is fast, comparable to the control of RC electric cars

1. The gearbox directly uses gear docking between the flywheel and the gearbox, and the gear ratio can be changed.
2. Each gear is equipped with multiple steel clutch plates to ensure the friction of each gear shift.
3. The transfer case has a reverse transmission function, which is suitable for most brands of remote control cars
4. The transfer case also has high and low speed gears, which is equivalent to having 6 forward gears
5. With built-in brakes, you don’t need to consider the installation position of the brakes of oil-powered vehicles when modifying the vehicle
6. Built-in servo installation, when modifying the vehicle, you don’t need to consider how to layout the servo
What are the advantages and disadvantages of this structure gearbox?
Advantages:
1. There is no need to cut off the power when shifting gears, and the clutch and shifting actions can be completed in one step
[Scenario: Assuming that the rc climbing car is going uphill and currently using the 2nd gear, it is found that the power is insufficient when encountering obstacles and needs to switch gears. If it is the current gearbox, you only need to directly shift gears. If it is an independent manual clutch gearbox, you may also need to release the clutch, press the brake, and perform three steps of shifting gears]
2. The reverse clutch design is adopted, that is, the default clutch is released. For RC climbing cars or RC speed cars, we cannot use our hands and feet at the same time like cars. In an emergency, we think it is more convenient to operate with the clutch released by default.
3. When the clutch is pressed tightly, it will not cause pressure on the engine, protecting the engine.
4. The gear shifting speed is fast. If the gear is controlled by the joystick, it can be operated as quickly as an electric motor. When moving forward in low gear, you can also reverse directly without stopping.
